| Inputs | 1 XLR ; 2 RCA |
| Speakers | 4 – 16 Ohms |
| Vacuum tube complement | 1 x 12AU7 ; 2 x EL84 |
| Output Power (per channel) | 8 Ohms : 15W CLASS A / 50W CLASS AB |
| 4 Ohms : 20W CLASS A / 60W CLASS AB | |
| Frequency response | 7Hz – 90kHz (-3dB) |
| Input Sensitivity | 300mV |
| Input Impedance | 100kOhms |
| Power Requirements | 230V |
| Power Consumption | 160W |
| Dimensions (W x D x H) | 45 x 35 x 22 (cm) (1 block) |
| Weight | 25kgs |
| Standard/High Dynamic Switch | Yes |
| Strong/Soft Bass Switch | Yes |
| Remote control | Included |
| OPTIONAL DAC | DAC 32bit / 384kHz (ES9038) |
| 1x SPDIF (RCA) input | |
| 1x optical input for TV etc. | |
| 1x USB (DSD 512) or 1 x BT 5.0 Aptx HD | |
| OPTIONAL Phono MM | 1 RCA input MM 40dB |
| OPTIONAL Phono MM/MC | 1 RCA input MM 40dB / MC 60dB |
M40 Mark II
SPECIFICATIONS
INTRODUCTION
Mavis M40 – Your First Step into the World of High-End Audio
The Mavis M40 Hybrid Tube Amplifier is designed for music lovers who want to experience the charm of tube sound without compromising on control, reliability, or value.
By combining the natural warmth and musicality of vacuum tubes with the stability and efficiency of solid-state amplification, the M40 delivers a smooth, engaging, and well-balanced listening experience that is easy to enjoy for hours.
Whether you’re building your first hi-fi system or upgrading from a conventional amplifier, the M40 offers an inviting sound signature with excellent detail, natural vocals, and impressive dynamics for its class.
Mavis M40 is a perfect introduction to authentic tube-inspired musical enjoyment
AUDIO SYSTEM SUGGESTION
IMAGES
